3M™ Medical Foam Tape, 1774W

"We've detected that you're visiting from {0}. Would you like to switch languages for tailored content?"

Hover over image to zoom

About the product

This single sided medical tape on a roll (1774W) is a thinner version of # 1773 foam tape. It consists of a closed cell, medium white polyethylene foam, coated with a pressure sensitive acrylic adhesive. The liner is a silicone treated, polyethylene coated, bleached Kraft paper, one side only. May be used for health care medical devices.

Product options

1-5 of Products

Select Filters to narrow your product list

Overall Width (Imperial)

Overall Width (Metric)

OverallLengthImperial

Overall Length (Metric)

Core Material

Product name	Product ID	Catalog number	Overall Width (Imperial)	Overall Width (Metric)	OverallLengthImperial	Overall Length (Metric)	Material	Core Material	Overall Thickness (Imperial)	Liner Weight (Metric)	Core Diameter (Metric)	OverallThicknessMetric	AdhesiveType	Category name	BackingMaterial	TapeColor	Conformability	Printable Backing	BackingCaliperMetric
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, 48in x 200yd, 3 Inch Fiber	Product ID 7100280375	Catalog number 1774W	Overall Width (Imperial) 48 in	Overall Width (Metric) 1219.2 mm	OverallLengthImperial 7200 in	Overall Length (Metric) 182.88 m	Material -	Core Material -	Overall Thickness (Imperial) -	Liner Weight (Metric) -	Core Diameter (Metric) -	OverallThicknessMetric -	AdhesiveType -	Category name Medical Component Foam Tapes	BackingMaterial -	TapeColor -	Conformability -	Printable Backing -	BackingCaliperMetric -
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, Configurable	Product ID 7100012363	Catalog number 1774W	Overall Width (Imperial) -	Overall Width (Metric) -	OverallLengthImperial -	Overall Length (Metric) -	Material Polyolefin Foam	Core Material -	Overall Thickness (Imperial) 23.622 mil	Liner Weight (Metric) 103 g/m²	Core Diameter (Metric) -	OverallThicknessMetric 0.6 mm	AdhesiveType Acrylic/Acrylate	Category name Medical Component Foam Tapes	BackingMaterial Polyolefin Foam	TapeColor White	Conformability High	Printable Backing true	BackingCaliperMetric 510 μm
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, 6 IN X 210 YD, 3 IN Fiber	Product ID 7010536126	Catalog number 1774W	Overall Width (Imperial) 6 in	Overall Width (Metric) 15.24 cm	OverallLengthImperial 7560 in	Overall Length (Metric) 192.024 m	Material Polyolefin Foam	Core Material Cardboard	Overall Thickness (Imperial) -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	AdhesiveType -	Category name Medical Component Foam Tapes	BackingMaterial -	TapeColor -	Conformability -	Printable Backing -	BackingCaliperMetric -
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, 48 IN X 210 YD, 3 IN Fiber, CUSTOMIZED	Product ID 7010510795	Catalog number 1774W	Overall Width (Imperial) 48 in	Overall Width (Metric) 121.92 cm	OverallLengthImperial 7560 in	Overall Length (Metric) 192.024 m	Material Polyolefin Foam	Core Material Cardboard	Overall Thickness (Imperial) -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	AdhesiveType -	Category name Medical Component Foam Tapes	BackingMaterial -	TapeColor -	Conformability -	Printable Backing -	BackingCaliperMetric -
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, 9.6 IN X 72 YD, 3 IN Plastic, CUSTOMIZED	Product ID 7010510637	Catalog number 1774W	Overall Width (Imperial) 9.6 in	Overall Width (Metric) 24.384 cm	OverallLengthImperial 2592.01 in	Overall Length (Metric) 65.837 m	Material Polyolefin Foam	Core Material Plastic	Overall Thickness (Imperial) -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	AdhesiveType -	Category name Medical Component Foam Tapes	BackingMaterial -	TapeColor -	Conformability -	Printable Backing -	BackingCaliperMetric -
3M™ Medical Foam Tape 1774W, Single Sided White Polyethylene, 63# liner, 5.2 IN X 288 YD, 3 IN Fiber, CUSTOMIZED	Product ID 7010510636	Catalog number 1774W	Overall Width (Imperial) 5.2 in	Overall Width (Metric) 13.208 cm	OverallLengthImperial 10367.99 in	Overall Length (Metric) 263.347 m	Material Polyolefin Foam	Core Material Cardboard	Overall Thickness (Imperial) -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	AdhesiveType -	Category name Medical Component Foam Tapes	BackingMaterial -	TapeColor -	Conformability -	Printable Backing -	BackingCaliperMetric -

Product details

Acrylic Adhesive
Fluid Resistant
Conformable
Good Processability

Product specifications

OverallLengthImperial	OverallLengthImperial 7200 in, 2592.01 in, 10367.99 in, 7560 in
Core Diameter (Metric)	Core Diameter (Metric) 7.62 cm
OverallWidthMetric	OverallWidthMetric 1219.2 mm, 15.24 cm
CoreDiameterMetric	CoreDiameterMetric 7.62 cm
OverallThicknessImperial	OverallThicknessImperial 23.622 mil
Overall Thickness (Metric)	Overall Thickness (Metric) 0.6 mm
Legacy SKU	Legacy SKU UU011952692\|7100280375, CY998758049, CY998758031, CY998788889, CY998759666, 70000126386
categoryName	categoryName Medical Component Foam Tapes
CoreMaterial	CoreMaterial Cardboard
BackingCaliperMetric	BackingCaliperMetric 510 μm
Core Material	Core Material Plastic, Cardboard
Category name	Category name Medical Component Foam Tapes
BackingMaterial	BackingMaterial Polyolefin Foam
LinerWeightMetric	LinerWeightMetric 103 g/m²
Adhesive Type	Adhesive Type Acrylic/Acrylate
Catalog number	Catalog number 1774W
Material	Material Polyolefin Foam
Overall Width (Metric)	Overall Width (Metric) 24.384 cm, 13.208 cm, 121.92 cm
Overall Length (Imperial)	Overall Length (Imperial) 7560 in
Overall Length (Metric)	Overall Length (Metric) 182.88 m, 65.837 m, 263.347 m, 192.024 m
OverallWidthImperial	OverallWidthImperial 48 in
GLBL_CAT_NBR	GLBL_CAT_NBR 1774W
Conformability	Conformability High
Tape Color	Tape Color White
PrintableBacking	PrintableBacking true
Overall Width (Imperial)	Overall Width (Imperial) 48 in, 9.6 in, 5.2 in
