3M™ Medical Foam Tape, 1770 Series

"We've detected that you're visiting from {0}. Would you like to switch languages for tailored content?"

Hover over image to zoom

About the product

This single sided medical foam tape on a roll consists closed cell, white polyethylene foam, coated with a pressure sensitive tackified acrylic adhesive. The liner is a silicone treated, polyethylene coated, bleached Kraft paper, one side only. The tape is wound with the liner on the outside of roll. May be used for health care medical devices.

Product options

1- of Products

Select Filters to narrow your product list

OverallWidthImperial

OverallWidthMetric

OverallLengthImperial

Overall Length (Metric)

Product name	Product ID	Catalog number	OverallWidthImperial	OverallWidthMetric	OverallLengthImperial	Overall Length (Metric)	Material	Core Material	OverallThicknessImperial	Liner Weight (Metric)	Core Diameter (Metric)	OverallThicknessMetric	Adhesive Type	categoryName	Backing Material	TapeColor	Conformability	PrintableBacking	Backing Caliper (Metric)
3M™ Medical Foam Tape 1773, Single Sided White Polyethylene, 83# Liner, 6 IN X 144 YD, 3 IN Fiber	Product ID 7100183937	Catalog number 1773	OverallWidthImperial 6 in	OverallWidthMetric 15.24 cm	OverallLengthImperial 5184.02 in	Overall Length (Metric) 131.674 m	Material Polyolefin Foam	Core Material Cardboard	OverallThicknessImperial -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	Adhesive Type -	categoryName Medical Component Foam Tapes	Backing Material -	TapeColor -	Conformability -	PrintableBacking -	Backing Caliper (Metric) -
3M™ Medical Foam Tape 1773, Single Sided White Polyethylene, 83# Liner, 48 IN x 72 YD, 3 IN Fiber, CUSTOMIZED	Product ID 7100104014	Catalog number 1773	OverallWidthImperial 48 in	OverallWidthMetric 1219.2 mm	OverallLengthImperial 2592.01 in	Overall Length (Metric) 65.837 m	Material Polyolefin Foam	Core Material Cardboard	OverallThicknessImperial -	Liner Weight (Metric) -	Core Diameter (Metric) 7.62 cm	OverallThicknessMetric -	Adhesive Type -	categoryName Medical Component Foam Tapes	Backing Material -	TapeColor -	Conformability -	PrintableBacking -	Backing Caliper (Metric) -
3M™ Medical Foam Tape 1773, Single Sided White Polyethylene, 83# Liner, Configurable	Product ID 7100084677	Catalog number 1773	OverallWidthImperial 48 in	OverallWidthMetric 121.92 cm	OverallLengthImperial -	Overall Length (Metric) -	Material Polyolefin Foam	Core Material -	OverallThicknessImperial 35.433 mil	Liner Weight (Metric) 135 g/m²	Core Diameter (Metric) -	OverallThicknessMetric 0.9 mm	Adhesive Type Acrylic/Acrylate	categoryName Medical Component Foam Tapes	Backing Material Polyolefin Foam	TapeColor White	Conformability Medium	PrintableBacking true	Backing Caliper (Metric) 790 μm

Product details

Medical Materials and Technologies helps health care manufacturers design and build more reliable, innovative and feature-rich medical devices. Customers leverage our technical expertise to select materials and technologies that integrate together for their break-through medical industry, device innovations designed for improving or enhancing lives.

Tackified Acrylic Adhesive
Fluid resistant
Adheres to High Surface Energy Substrates
Good Processability

Suggested Applications

Printable for potential graphic or labeling applications on skin

Product specifications

Liner Weight (Metric)	Liner Weight (Metric) 135 g/m²
Backing Caliper (Metric)	Backing Caliper (Metric) 790 μm
Core Diameter (Metric)	Core Diameter (Metric) 7.62 cm
Catalog number	Catalog number 1773
Overall Thickness (Imperial)	Overall Thickness (Imperial) 35.433 mil
CoreDiameterMetric	CoreDiameterMetric 7.62 cm
Material	Material Polyolefin Foam
OverallWidthMetric	OverallWidthMetric 121.92 cm
Overall Thickness (Metric)	Overall Thickness (Metric) 0.9 mm
Legacy SKU	Legacy SKU 7100183937\|UU009722586, 7100104014\|UU008083857, 70000028384
Overall Length (Imperial)	Overall Length (Imperial) 5184.02 in, 2592.01 in
Overall Width (Metric)	Overall Width (Metric) 15.24 cm, 1219.2 mm
Overall Length (Metric)	Overall Length (Metric) 131.674 m, 65.837 m
Core Material	Core Material Cardboard
Conformability	Conformability Medium
Category name	Category name Medical Component Foam Tapes
Printable Backing	Printable Backing true
Overall Width (Imperial)	Overall Width (Imperial) 6 in, 48 in
Backing Material	Backing Material Polyolefin Foam
Adhesive Type	Adhesive Type Acrylic/Acrylate
TapeColor	TapeColor White
