3M™ Microfluidic Diagnostic Tape, 9795R
Hover over image to zoom
About the product
3M™ Microfluidic Diagnostic Tape 9795R, Single Sided Clear Delayed Tack Adhesive Tape, consists of a clear polypropylene film coated on one side with a pressure sensitive silicone adhesive. The tape is supplied on a white fluoro-silicone coated polyester release liner. The product is designed for use in diagnostic medical devices such as test strip, lab-on-a-chip and PCR applications.
Product options
1-5 of 16 Products
Select Filters to narrow your product list
| Product name and IDs | 3M ID | Overall Width (Imperial) | Overall Length (Imperial) | Overall Length (Metric) | Overall Width (Metric) | Product Form | Material | Overall Thickness (Imperial) | Liner Material | Overall Thickness (Metric) | Adhesive Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
3M ID 7100280374 |
Overall Width (Imperial) 48.03 inch |
Overall Length (Imperial) 3937.01 inch |
Overall Length (Metric) 100 meter |
Overall Width (Metric) 1220 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100273469 |
Overall Width (Imperial) 48.03 inch |
Overall Length (Imperial) 5905.51 inch |
Overall Length (Metric) 150 meter |
Overall Width (Metric) 1220 millimeter |
Product Form Roll |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type Silicone |
|
|
3M ID 7100243587 |
Overall Width (Imperial) 23.98 inch |
Overall Length (Imperial) 5905.51 inch |
Overall Length (Metric) 150 meter |
Overall Width (Metric) 609 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100236831 |
Overall Width (Imperial) 48.03 inch |
Overall Length (Imperial) 1968.5 inch |
Overall Length (Metric) 50 meter |
Overall Width (Metric) 1220 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100235175 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100229206 |
Overall Width (Imperial) 3.07 inch |
Overall Length (Imperial) 19685.04 inch |
Overall Length (Metric) 500 meter |
Overall Width (Metric) 78 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100229205 |
Overall Width (Imperial) 6.06 inch |
Overall Length (Imperial) 15748.03 inch |
Overall Length (Metric) 400 meter |
Overall Width (Metric) 154 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type Silicone |
|
|
3M ID 7100229200 |
Overall Width (Imperial) 5.88 inch |
Overall Length (Imperial) 18432.01 inch |
Overall Length (Metric) 468.173 meter |
Overall Width (Metric) 149.225 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type Silicone |
|
|
3M ID 7100229199 |
Overall Width (Imperial) 24 inch |
Overall Length (Imperial) 5184.02 inch |
Overall Length (Metric) 131.674 meter |
Overall Width (Metric) 609.6 millimeter |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type Silicone |
|
|
3M ID 7100224806 |
Overall Width (Imperial) 48 inch |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) 121.92 centimeter |
Product Form - |
Material Polyolefin |
Overall Thickness (Imperial) 3.937 milliinch |
Liner Material Polyester |
Overall Thickness (Metric) 100 micrometer |
Adhesive Type Silicone Acrylic/Acrylate |
|
|
3M ID 7100191484 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100148113 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100140636 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7100000226 |
Overall Width (Imperial) 48 inch |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) 121.92 centimeter |
Product Form - |
Material Polyolefin |
Overall Thickness (Imperial) 3.937 milliinch |
Liner Material Polyester |
Overall Thickness (Metric) 100 micrometer |
Adhesive Type Silicone Acrylic/Acrylate |
|
|
3M ID 7010510831 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
|
|
3M ID 7010510829 |
Overall Width (Imperial) - |
Overall Length (Imperial) - |
Overall Length (Metric) - |
Overall Width (Metric) - |
Product Form - |
Material - |
Overall Thickness (Imperial) - |
Liner Material - |
Overall Thickness (Metric) - |
Adhesive Type - |
Product details
- Optically clear
- Bioassay compatible adhesive (based on compatibility with industry typical reagents )
- Chemically inert
- Low autofluorescence
- Adheres to a wide variety of substrates
- Delayed tack adhesive
- Low extractables
- Non-hemolytic
- Non-toxic to mammalian cells
Product specifications
| Product Form |
Product Form
Roll |
| Overall Length (Imperial) |
Overall Length (Imperial)
3937.01 inch, 18432.01 inch, 5184.02 inch, 1968.5 inch, 19685.04 inch, 15748.03 inch, 5905.51 inch |
| Overall Width (Metric) |
Overall Width (Metric)
1220 millimeter, 149.225 millimeter, 609.6 millimeter, 121.92 centimeter, 78 millimeter, 154 millimeter, 609 millimeter |
| Overall Length (Metric) |
Overall Length (Metric)
100 meter, 468.173 meter, 131.674 meter, 50 meter, 500 meter, 400 meter, 150 meter |
| Overall Thickness (Imperial) |
Overall Thickness (Imperial)
3.937 milliinch |
| Overall Thickness (Metric) |
Overall Thickness (Metric)
100 micrometer |
| Material |
Material
Polyolefin |
| Overall Width (Imperial) |
Overall Width (Imperial)
48.03 inch, 5.88 inch, 24 inch, 48 inch, 3.07 inch, 6.06 inch, 23.98 inch |
| Liner Material |
Liner Material
Polyester |
| Adhesive Type |
Adhesive Type
Silicone, Silicone Acrylic/Acrylate |
