About the product

3M™ LifeASSURE™ BDA Series Filter Cartridges are dual-layer, asymmetric microporous PES membrane filters for sterile filtration designed for bottled water and other beverage processing applications. Combined with 3M’s particle control and pre-filtration filters, these cartridges offer bottlers a complete solution for rigorous contaminant control with a long service life and low operating costs.

Ask an expert

Find a distributor

Product options

1-5 of Products

Select Filters to narrow your product list

Overall Length (Imperial)

Overall Length (Metric)

End Modification

Industries

Product name	Product ID	Overall Length (Imperial)	Overall Length (Metric)	Overall Diameter (Imperial)	Overall Diameter (Metric)	Product Type	End Modification	Product Form	Filter Type	Grade	Micron Rating (Absolute)	Filter Technology	Industries	Product Series	Brand	Category name
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F04BA, 40 in, 0.2 um,226/Spear, Silicone, 6/Case	Product ID 7010381548	Overall Length (Imperial) 40 in	Overall Length (Metric) 101.6 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-ring & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F03BB, 30 in, 0.2 um,226/Spear, Fluorocarbon, 6/Case	Product ID 7010301285	Overall Length (Imperial) 30 in	Overall Length (Metric) 76.2 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-ring & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F03BC, 30 in, 0.2 um,226/Spear, EPR, 6/Case	Product ID 7000051169	Overall Length (Imperial) 30 in	Overall Length (Metric) 76.2 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-ring & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F03FA, 30 in, 0.2 um,222/Flat Cap, Silicone, 6/Case	Product ID 7000051044	Overall Length (Imperial) 30 in	Overall Length (Metric) 76.2 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 222 O-ring & Flat Cap	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F01BA, 10 in, 0.2 um,226/Spear, Silicone, 6/Case	Product ID 7000050945	Overall Length (Imperial) 10 in	Overall Length (Metric) 25.4 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-Rings & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F03BA, 30 in, 0.2 um,226/Spear, Silicone, 6/Case	Product ID 7000050940	Overall Length (Imperial) 30 in	Overall Length (Metric) 76.2 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-ring & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges
3M™ LifeASSURE™ BDA Series Filter Cartridge, BDA020F02BA, 20 in, 0.2 um,226/Spear, Silicone, 6/Case	Product ID 7000050939	Overall Length (Imperial) 20 in	Overall Length (Metric) 50.8 cm	Overall Diameter (Imperial) 2.76 in	Overall Diameter (Metric) 7 cm	Product Type Pleated Membrane	End Modification 226 O-ring & Spear	Product Form Cartridge	Filter Type Surface	Grade BDA020	Micron Rating (Absolute) 0.2 absolute, @ 99.9%	Filter Technology Membrane	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries	Product Series BDA	Brand LifeASSURE™	Category name Pleated Membrane Cartridges

Product details

Durable construction.

3M™ LifeASSURE™ BDA Series Filter Cartridges are highly durable and capable of secure operation through numerous cycles of hot water sanitation, steam sterilization and chemical-based cleaning and sanitation.

Highly asymmetric BDA membrane.

3M™ LifeASSURE™ BDA Series Filter Cartridges incorporates a dual-layer asymmetrical membrane that reduces flow resistance, which results in a lower pressure drop, fewer filters required, a greater contaminant retention capacity and a longer service life.

Advanced Pleat Technology (APT).

3M’s APT design helps to maximize the useful surface area of the filter while maintaining open flow paths between the media pleats. It also provides lower pressure drop, a longer service life and lower overall operational costs.

Robust media support design.

Combining the special upstream and downstream membrane support layers with the APT design greatly increases per-cartridge flow rates, resulting in lower overall operational costs and a longer service life.

3M™ LifeASSURE™ BDA Series Filter Cartridges contain two layers of PES membrane. The upstream layer is rated at 0.65 μm while the downstream layer is rated at 0.2 μm. Our testing has shown this arrangement results in a long service life while maintaining the necessary retention of microorganisms. 3M™ LifeASSURE™ BDA Series Filter Cartridges have been validated with a 0.2 μm rating for complete retention of Brevundimonas diminuta (B. diminuta) (ATCC 19146) at a concentration of 10 7 CFU/cm2 or greater.

Validated 0.2 μm absolute-rated membrane for reliable sterile filtration
Asymmetric dual-layer polyethersulfone membrane provides a high capacity and long service life to help reduce costs
Advanced Pleat Technology (APT) construction provides an extremely high surface area for higher throughputs
Secures operation through numerous cycles of hot water sanitation, steam sterilization and standard chemical-based cleaning and sterilization
Extensive food contact compliance* *For details related to specific use conditions or limitations for food contact applications please contact your 3M Representative for more information

Suggested Applications

Bottled Water
Soft Drinks
Process Water
Intermediates and Ingredients
Syrups
Dyes and Flavors

Product specifications

Industries	Industries Breweries,Food & beverage manufacturing,Manufacturing,Soft drink manufacturing,Wineries
Product Form	Product Form Cartridge
Filter Technology	Filter Technology Membrane
Grade	Grade BDA020
Micron Rating (Absolute)	Micron Rating (Absolute) 0.2 absolute, @ 99.9%
Product Series	Product Series BDA
Brand	Brand LifeASSURE™
Overall Length (Imperial)	Overall Length (Imperial) 30 in, 40 in, 10 in, 20 in
Overall Diameter (Imperial)	Overall Diameter (Imperial) 2.76 in
Overall Length (Metric)	Overall Length (Metric) 76.2 cm, 101.6 cm, 25.4 cm, 50.8 cm
Product Type	Product Type Pleated Membrane
Overall Diameter (Metric)	Overall Diameter (Metric) 7 cm
End Modification	End Modification 226 O-ring & Spear, 226 O-Rings & Spear, 222 O-ring & Flat Cap
Category name	Category name Pleated Membrane Cartridges
Filter Type	Filter Type Surface
