3M™ CoTran™ Ethylene Vinyl Acetate Membrane Film, 9702
- 1/15
- 2/15
- 3/15
- 4/15
- 5/15
- 6/15
- 7/15
- 8/15
- 9/15
- 10/15
- 11/15
- 12/15
- 13/15
- 14/15
- 15/15
About the product
Non-porous, rate-controlling EVA membrane, 2 mils thick, 9%VA
| Product name and IDs | 3M ID | Overall Width (Imperial) | Overall Length (Imperial) | Overall Length (Metric) | Overall Width (Metric) | Product Color | OverallThicknessImperial | BackingCarrierMaterial | Overall Thickness (Metric) | Brand | Category name |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
7100150772 | - | - | - | - | - | - | Ethylene Vinyl Acetate | - | CoTran™ | Transdermal Films & Laminates |
|
|
7100074931 | 37.6 in | 70078.74 in | 1780 m | 955 mm | - | - | Ethylene Vinyl Acetate | - | CoTran™ | Transdermal Films & Laminates |
|
7100000164 | 48.03 in | 47244.09 in | 1200 m | 122 cm | Transparent | 2 mil | Ethylene Vinyl Acetate | 50.8 μm | CoTran™ | Transdermal Films & Laminates |
|
|
7010296679 | 6 in | 900 in | 22.86 m | 152.4 mm | - | - | Ethylene Vinyl Acetate | - | CoTran™ | Transdermal Films & Laminates |
Product details
- Translucent
- Matte finish on one side
- Non-corona treated
- 9% Vinyl Acetate
Product specifications
| ProductColor |
ProductColor
Transparent |
| OverallLengthImperial |
OverallLengthImperial
70078.74 in |
| Overall Thickness (Imperial) |
Overall Thickness (Imperial)
2 mil |
| Overall Thickness (Metric) |
Overall Thickness (Metric)
50.8 μm |
| OverallWidthMetric |
OverallWidthMetric
122 cm |
| categoryName |
categoryName
Transdermal Films & Laminates |
| Brand |
Brand
CoTran™ |
| OverallLengthMetric |
OverallLengthMetric
1200 m |
| Overall Width (Metric) |
Overall Width (Metric)
955 mm, 152.4 mm |
| Overall Length (Imperial) |
Overall Length (Imperial)
47244.09 in, 900 in |
| Overall Length (Metric) |
Overall Length (Metric)
1780 m, 22.86 m |
| Category name |
Category name
Transdermal Films & Laminates |
| BackingCarrierMaterial |
BackingCarrierMaterial
Ethylene Vinyl Acetate |
| Overall Width (Imperial) |
Overall Width (Imperial)
37.6 in, 48.03 in |
| Backing (Carrier) Material |
Backing (Carrier) Material
Ethylene Vinyl Acetate |
