3M™ LifeASSURE™ BFS Series Filter Cartridge
Solventum’s Purification and Filtration Business is now a part of Thermo Fisher Scientific. Drinking Water Filtration remains with Solventum. For more information, please visit here.
About the product
3M™ LifeASSURE™ BFS Series Filter Cartridges are PTFE microporous hydrophobic straight pleat membrane filters used in processes requiring 0.2 µm sterile and microbial-rated air filtration for food and beverage, microelectronics and other industrial applications. Offering excellent air flow for vent filter assemblies, they prevent moisture blockage to increase the throughput and filter life.
Product details
High efficiency contaminant reduction.
3M™ LifeASSURE™ BFS Series Filter Cartridge
3M™ LifeASSURE™ BFS Series Filter Cartridges are made with a hydrophobic PTFE membrane. The inner and outer non-woven polypropylene layers provide upstream and downstream support which allow better flow access through the membrane pleats. A second polypropylene downstream flow distribution layer further enhances airflow. Available in 10, 20 and 30-inch sizes, these filter cartridges have a standard straight pleat and a filter rating of 0.2 µm, allowing them to be used for sterilization.
The cartridge hardware components consist of an inner and outer cage made of molded polypropylene. End cap adapters and O-ring adapters are also constructed of polypropylene and contain a 316 stainless steel ring or an embedded polyethersulfone (PES) core for structural stability. All filter cartridge components are assembled by thermal bonding.
- PTFE microporous straight pleated membrane filter cartridges for sterile air/gas filtration
- Qualified for Log Reduction Values (LRV) in excess of 7 with Brevundimonas diminuta (B. diminuta)
- Hydrophobic polytetrafluoroethylene (PTFE) membrane increases throughput and filter life in wet or dry conditions
- 100% forward flow integrity tested prior to shipping
- Standard straight pleat design available in 10, 20, 30-inch sizes
- Extensive food contact compliance* *For details related to specific use conditions or limitations for food contact applications please contact your 3M Representative for more information.
Suggested Applications
- Food and Beverage: Sterile venting of process tanks, sterile filtration of process air and aseptic filling lines, sterile air filtration on blow, fill and seal machines, sterilizing filtration of fermentation inlet and exhaust air
- Microelectronics: High purity chemicals, organic solvents, photoresists, anti-reflective coatings, plating solutions
- Other industrial applications that require sterile or microbial-rated air filtration and/or sterile filtration of aggressive liquids
Product specifications
| OverallLengthImperial |
OverallLengthImperial
10 in, 30 in, 20 in |
| Filter Technology |
Filter Technology
Membrane |
| ProductForm |
ProductForm
Cartridge |
| OverallDiameterImperial |
OverallDiameterImperial
2.76 in |
| Micron Rating (Absolute) |
Micron Rating (Absolute)
0.2 absolute, @ 99.9% |
| Product Series |
Product Series
BFS |
| MicronRatingAbsolute |
MicronRatingAbsolute
0.2 absolute, @ 99.9% |
| categoryName |
categoryName
Pleated Membrane Cartridges |
| OverallLengthMetric |
OverallLengthMetric
76.2 cm, 25.4 cm, 50.8 cm |
| End Modification |
End Modification
222 O-ring & Flat Cap, 222 O-ring & Spear, 226 O-ring & Spear |
| Category name |
Category name
Pleated Membrane Cartridges |
| ProductSeries |
ProductSeries
BFS |
| Trademark2 |
Trademark2
LifeASSURE™ |
| Product Form |
Product Form
Cartridge |
| OverallDiameterMetric |
OverallDiameterMetric
7 cm |
| ProductType |
ProductType
Pleated Membrane |
| Grade |
Grade
BFS020 |
| EndModification |
EndModification
222 O-ring & Flat Cap, 226 O-ring & Spear, 222 O-ring & Spear |
| Brand |
Brand
LifeASSURE™ |
| FilterType |
FilterType
Surface |
| Overall Diameter (Imperial) |
Overall Diameter (Imperial)
2.76 in |
| Overall Length (Imperial) |
Overall Length (Imperial)
10 in, 20 in, 30 in |
| Overall Length (Metric) |
Overall Length (Metric)
25.4 cm, 50.8 cm, 76.2 cm |
| Product Type |
Product Type
Pleated Membrane |
| Overall Diameter (Metric) |
Overall Diameter (Metric)
7 cm |
| Filter Type |
Filter Type
Surface |
| FilterTechnology |
FilterTechnology
Membrane |
