3M™ Aqua-Pure™ Whole House Sanitary Quick Change Replacement Water Filter Cartridge AP917HD
About the product
We manufacture the 3M™ Aqua-Pure™ Whole House Sanitary Quick Change Replacement Water Filter Cartridge AP917HD for the AP903 system as an activated carbon filter with a nominal heavy duty particulate reduction rating of 5 microns and a 100,000 gallon capacity. This cartridge design is suitable for use on both chlorinated (municipal) and non-chlorinated (well water) systems.
| Product name and IDs | 3M ID | Overall Width (Imperial) | Overall Width (Metric) | Micron Rating | Flow Rate (Imperial) | Overall Height (Imperial) | Overall Height (Metric) | Flow Rate (Metric) | Product Colour | Filter Type | Net Weight (Metric) | CapacityImperial | Capacity (Metric) | Application | Industries | ProductSeries | Brand |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7100039299 | 4.5 in | 11.43 cm | 5 μm | 10 gal/min | 20.75 in | 52.705 cm | 37.85 l/min | Blue | SQC | 1.6 kg | 100000 gal (us) | 378541 l | Whole house water filtration | Consumer water | AP | Aqua-Pure™ |
|
7100007625 | 4.5 in | 11.43 cm | 5 μm | 10 gal/min | 20.75 in | 52.705 cm | 37.85 l/min | Blue | SQC | 1.4 kg | 100000 gal (us) | 378541 l | Whole house water filtration | Consumer water | AP | Aqua-Pure™ |
|
7000029542 | 4.5 in | 11.43 cm | 5 μm | 10 gal/min | 20.75 in | 52.705 cm | 37.85 l/min | Blue | SQC | 1.63 kg | 100000 gal (us) | 378541 l | Whole house water filtration | Consumer water | AP | Aqua-Pure™ |
Product details
Our 3M™ Aqua-Pure™ Whole House Sanitary Quick Change Replacement Water Filter Cartridge AP917HD for the AP903 system reduces sediment, chlorine taste and odour at a flow rate of up to 10 GPM to meet the needs of large homes with at least 2.5 bathrooms.. Our innovative Sanitary Quick Change (SQC) design, allows for fast and easy cartridge change-outs without having to contact the filter media or the need for a filter wrench. Our Sanitary Quick Change (SQC) is one of the industry's most advanced whole house water filtration system features for this application and also minimizes contact with the filter media.
Features include:
- Filter cartridge is o-ring seal type
- Maximum flow rate is up to 75.7 lpm*
- AP917HD Filter Cartridge incorporates carbon block filtration with a non-woven pleat media
- Cartridges are sanitary in design, requiring no contact with the filter media during cartridge change-out
A Track Record of Success
3M, a household brand name, is a known leader in filtration technology and recognized for innovation, trust and quality around the world and 3M branded water filtration products have been addressing water quality issues for over 50 years. 3M products offer a wide range of solutions designed to address many types of water quality concerns. Third-party certifications, such as NSF and WQA, are a quality advantage we strive to provide on many 3M water quality improvement solutions.
Water: Nothing’s Closer to Home
Having clean and clear drinking water in your home is as pleasurable as it is reassuring to know that you're giving your family the best. With a water filtration system from 3M Purification, you can provide filtered drinking water for every member of your family. From whole home water filtration to drinking water systems, look to 3M Purification to help you find the right solution.
*As tested by manufacturer’s laboratory
- Replacement cartridge provides up to 454,609 litre capacity, approximately one year cartridge life, dependent upon water quality conditions
- Up to 75.7 litres per minute (LPM) flow rate
- Sanitary Quick Change (SQC) design allows for fast and easy cartridge change-outs without a filter wrench
- Whole house water filtration helps reduce sediment build-up in water heaters and appliances
Suggested Applications
- Use as a replacement filter cartridge for the AP902 system
Product specifications
| Industries |
Industries
Consumer water |
| Net Weight (Metric) |
Net Weight (Metric)
1.4 kg, 1.63 kg |
| Micron Rating |
Micron Rating
5 μm |
| OverallWidthMetric |
OverallWidthMetric
11.43 cm |
| Product Series |
Product Series
AP |
| CapacityImperial |
CapacityImperial
100000 gal (us) |
| categoryName |
categoryName
Replacement Water Filter Cartridges |
| Flow Rate (Imperial) |
Flow Rate (Imperial)
10 gal/min |
| OverallHeightImperial |
OverallHeightImperial
20.75 in |
| Overall Height (Imperial) |
Overall Height (Imperial)
20.75 in |
| OverallHeightMetric |
OverallHeightMetric
52.705 cm |
| FlowRateImperial |
FlowRateImperial
10 gal/min |
| NetWeightMetric |
NetWeightMetric
1.6 kg |
| Capacity (Imperial) |
Capacity (Imperial)
100000 gal (us) |
| ProductSeries |
ProductSeries
AP |
| Category name |
Category name
Replacement Water Filter Cartridges |
| Trademark2 |
Trademark2
Aqua-Pure™ |
| Overall Height (Metric) |
Overall Height (Metric)
52.705 cm |
| FlowRateMetric |
FlowRateMetric
37.85 l/min |
| Product Colour |
Product Colour
Blue |
| ProductColor |
ProductColor
Blue |
| CapacityMetric |
CapacityMetric
378541 l |
| Capacity (Metric) |
Capacity (Metric)
378541 l |
| Flow Rate (Metric) |
Flow Rate (Metric)
37.85 l/min |
| Brand |
Brand
Aqua-Pure™ |
| FilterType |
FilterType
SQC |
| Overall Width (Metric) |
Overall Width (Metric)
11.43 cm |
| OverallWidthImperial |
OverallWidthImperial
4.5 in |
| Filter Type |
Filter Type
SQC |
| Application |
Application
Whole house water filtration |
