3M™ High Flow Series System for Ice Applications
3M Drinking Water Filtration is now Aqua-Pure™ Water Filtration. You will notice continuous branding updates throughout this transition.
About the product
We designed the 3M™ High Flow Series System for Ice Applications, Model ICE140-S which provides consistent high-quality water by reducing particulate, chlorine taste and odour, cyst, bacteria, and scale. The Sanitary Quick Change (SQC) design allows for easy cartridge change-outs.
Product details
- Provides consistent high quality water
- Reduces particulate, chlorine taste and odour, cyst, and bacteria from incoming water
- Built-in scale inhibition can help to prevent the potentially harmful effects of scale build-up on equipment
- Integrated Membrane Pre-Activated Carbon Technology (“I.M.P.A.C.T.”) filtration media combines a membrane with a premium activated carbon block to help provide excellent throughput and cartridge life
- Valve-in-head design
- Sanitary Quick Change (SQC) encapsulated cartridge design allows for fast and easy cartridge change-outs without the need for a filter wrench
- System designed for use in ice applications involving commercial cubers up to 1,000 lbs. (453.6 kg.) and commercial flakers up to 1,800 lbs. (816.5 kg.)
- Includes replacement cartridge Model HF40-S
Suggested Applications
- Point of use sediment and CTO filter with scale Inhibition for use with various food service applications specifically Ice Machines
Product specifications
| Industries |
Industries
Commercial water,Food services & drinking places,Healthcare,Hospitality |
| Micron Rating |
Micron Rating
3 μm, 0.2 μm |
| Product Series |
Product Series
ICE190, ICE120, ICE140, ICE160 |
| OverallWidthMetric |
OverallWidthMetric
10.16 cm, 20.32 cm, 47.32 cm |
| CapacityImperial |
CapacityImperial
25000 gal (us), 35000 gal (us) |
| categoryName |
categoryName
Beverage Appliance Filtration |
| Flow Rate (Imperial) |
Flow Rate (Imperial)
4.993 gal/min, 1.506 gal/min, 1.67 gal/min, 6.684 gal/min, 3.329 gal/min |
| OverallHeightImperial |
OverallHeightImperial
17.5 in, 24.56 in, 18.13 in |
| Overall Height (Imperial) |
Overall Height (Imperial)
24.19 in, 15.56 in, 17.5 in, 24.56 in, 18.13 in |
| OverallHeightMetric |
OverallHeightMetric
39.52 cm, 44.45 cm, 62.38 cm |
| FlowRateImperial |
FlowRateImperial
2.087 gal/min, 6.684 gal/min, 3.329 gal/min, 2.51 gal/min |
| Capacity (Imperial) |
Capacity (Imperial)
54000 gal (us), 9000 gal (us), 14000 gal (us), 10000 gal (us), 70000 gal (us), 35000 gal (us), 25000 gal (us) |
| Category name |
Category name
Beverage Appliance Filtration |
| ProductSeries |
ProductSeries
ICE120, ICE190, ICE260 |
| Overall Height (Metric) |
Overall Height (Metric)
61.44 cm, 44.45 cm, 62.38 cm, 46.05 cm, 39.52 cm |
| FlowRateMetric |
FlowRateMetric
18.9 l/min, 6.322 l/min, 25.3 l/min, 12.6 l/min |
| MicronRating |
MicronRating
0.5 μm, 3 μm, 1 μm, 0.2 μm |
| CapacityMetric |
CapacityMetric
52996 l, 264978 l, 132489 l |
| Capacity (Metric) |
Capacity (Metric)
204412 l, 34069 l, 94635 l, 37854 l, 264978 l, 132489 l |
| Flow Rate (Metric) |
Flow Rate (Metric)
5.7 l/min, 18.9 l/min, 7.9 l/min, 25.3 l/min, 12.6 l/min, 9.5 l/min |
| FilterType |
FilterType
SQC |
| Overall Width (Metric) |
Overall Width (Metric)
20.32 cm, 10.16 cm, 11.3 cm |
| OverallWidthImperial |
OverallWidthImperial
8 in, 4 in, 18.63 in |
| Filter Type |
Filter Type
SQC |
| Overall Width (Imperial) |
Overall Width (Imperial)
4 in, 8 in, 4.45 in, 18.63 in |
